1.Adopt imported parts, cutting, stripping( half stripping), crimping, twisting automatically, simple to operate, precise and stable
2.Stripping length,cable pressing wheel, cutting depth are controlled by touch screen, easy and quick.
3. Easy and quick to adjust technical characteristic.
|
Voltage |
AC220V/50HZ |
|
Function |
Wire cutting, stripping, crimping, twisting |
|
Productivity (500mm) |
8000pcs/h(no twisting)；6200pcs/h (twisting) |
|
Wire Range |
AWG#32—AWG#18 |
|
Cutting length |
25mm-9999mm |
|
Cutting accuracy |
Adjustable |
|
Stripping length |
0.1mm—25mm |
|
Crimping force |
1.5Ton |
|
Twisting length |
3 mm—20mm |
|
Auxiliary device |
Sending device, terminal conveyor, garbage collection |
|
Testing Equipment |
Terminal and wire input testing |
|
Dimension |
1060W*600L*1380H(mm) |
|
Weight |
300kg |
Accessories
