This equipment is mainly used for post-processing of medical plastic catheter ends.
Using manual feeding, it is composed of three stations, such as clamping component, water tank component, and high-frequency heating component. The mold is heated by high-frequency induction, and the pipe is clamped and pushed into the mold with an air cylinder, so that the pipe becomes type. Users can input parameters through the touch screen to adjust the process.
Specification
（1）The structure mainly includes：The mechanical part is composed of frame, finger cylinder, high frequency heating, air source and so on. The electrical part is composed of PLC all-in-one machine, switching power supply, thermometer and so on.
（2）Hot melt machine equipment parameters
Equipment Size：600mm（L）×500mm（W）×380mm（H） Weight：35KG
Power supply：single phase AC220V，10A，50HZ
Air Pressure：0.5~0.8Mpa
Power：0.15KW
ambient temperature：-20℃＋50℃
Operate Worker：1
Forming Speed：600-1200PCS/H
Chiller
Power supply：single phase AC220V，Power: 1.2KW
Equipment Size：600*540*30MM
