Apply to the communications industry, medical and automotive industry, all kinds of flexible and semi-flexible coaxial cables, charging cable, BV cable, corrugated tube cable, medical cable stripping, tidy, precise and not hurt conductor.
Men-machine interface, easy to operate, maximum peeling 9 layers, can store max 99 processing program.
The design of rotary cutter head and four rotary knives, and exquisite structure improve stripping stability and blade tools working life.
It adopts servo motor, high precision ball screw drive and multi-point motion control system, stability and high efficiency.
Blades adopts imported tungsten steel, and can be coated with titanium alloy, sharp and durable.
It can meet many special requirements, such as multi-layer peeling, multi-section peeling, automatic continuous starting, etc.
Specification
Model: AM6092
Display: Touch screen(Chinese and English language)
Interface: LCD 95*50MM
Suitable cable: Coaxial cable, corrugated tube cable, BV cable, New energy wire harness
Voltage: AC220V/110V 50/60HZ
Power: 240W
Dimension: 720*230*350mm
Wight: 40KG
Stripping length: ø0.1mm-ø90mm
Stripping length setting unit: 0.01mm
Cutting deepth setting unit: 0.01mm
Cutting diameter range: ø3.0-ø18mm
Drive mode: motor/ ball screw drive
Stripping way: rotary blade
Maximum peeling layers: 9 layers
Blade: Imported tungsten steel
Work environment:-5---45 degrees, dry and vibration-free work surface
Shenzhen Aituo Automation Device Co.,Ltd
